规格尺寸 Specifications and dimensions
规格 Specifications | 管外径 Pipe OD(mm) | 外径 Pipe OD(mm) | 孔径 Bore Size (mm) | 规格 Specifications | 管外径 Pipe OD(inch) | 管外径 Pipe OD(inch) | 孔径 Bore Size (mm) |
TRPG06-04 | 6 | 4 | 3.2 | TRPG1/4-3/16 | 1/4 | 3/16 | 4 |
TRPG08-06 | 8 | 6 | 5 | TRPG5/16-1/4 | 5/16 | 1/4 | 5 |
TRPG10-08 | 10 | 8 | 7 | TRPU3/8-5/16 | 3/8 | 5/16 | 7 |
TRPG12-10 | 12 | 10 | 9 | ||||
| TRPG14-12 | 14 | 12 | 11 |
外形尺寸 Overall dimensions
规格 Specifications | DI | D2 | A1 | A2 | B1 | B2 | L |
TRPG06-04 | 4 | 6 | 11±0.2 | 13±0.2 | 3.2±0.12 | 5±0.12 | 32±0.5 |
TRPG08-06 | 6 | 8 | 13±0.2 | 15±0.2 | 5±0.12 | 7±0.12 | 37±0.5 |
TRPG10-08 | 8 | 10 | 15±0.2 | 18.5±0.2 | 7±0.12 | 9±0.12 | 43±0.5 |
TRPG12-10 | 10 | 12 | 18.5±0.2 | 20.5±0.2 | 9±0.12 | 11±0.12 | 47±0.5 |
TRPG14-12 | 12 | 14 | 20.5±0.2 | 23±0.2 | 11±0.12 | 13±0.12 | 48.5±0.5 |
TRPG1/4-3/16 | 3/16 | 1/4 | 13±0.2 | 15±0.2 | 4±0.12 | 5±0.13 | 37±0.5 |
TRPG5/16-1/4 | 1/4 | 5/16 | 13±0.2 | 15±0.2 | 5±0.12 | 7±0.12 | 37±0.5 |
TRPU3/8-5/16 | 5/16 | 3/8 | 15±0.2 | 18.5±0.2 | 7±0.12 | 9±0.12 | 43±0.5 |
