规格尺寸 Specifications and dimensions
规 格 Specifications | 管外径 Pipe OD(mm) | 规 格 Specifications | 管外径 Pipe OD(inch) |
ERPUB3 | 3 | ERPUB1/8 | 1/8 |
ERPUB4 | 4 | ERPUB3/16 | 3/16 |
ERPUB5 | 5 | ERPUB1/4 | 1/4 |
ERPUB6 | 6 | ERPUB5/16 | 5/16 |
ERPUB7 | 7 | ERPUB3/8 | 3/8 |
ERPUB8 | 8 | ERPUB1/2 | 1/2 |
ERPUB8.5 | 8.5 | ||
ERPUB10 | 10 | ||
ERPUB12 | 12 | ||
| ERPUB14 | 14 | ||
ERPUB15 | 15 | ||
ERPUB16 | 16 | ||
ERPUB18 | 18 | ||
ERPUB20 | 20 | ||
ERPUB22 | 22 | ||
| ERPUB25 | 25 |
外形尺寸 Overall dimensions
| 规 格 Specifications | D | A | L |
ERPUB3 | 3 | 11±0.2 | 16.2±0.5 |
ERPUB4 | 4 | 11±0.2 | 16.2±0.5 |
ERPUB5 | 5 | 13.5±0.2 | 18.7±0.5 |
ERPUB6 | 6 | 13.5±0.2 | 18.7±0.5 |
ERPUB7 | 7 | 15.2±0.2 | 19.2±0.5 |
ERPUB8 | 8 | 15.2±0.2 | 19.2±0.5 |
ERPUB8.5 | 8.5 | 15.2±0.2 | 19.2±0.5 |
ERPUB10 | 10 | 17.5±0.2 | 20.4±0.5 |
ERPUB12 | 12 | 21.5±0.2 | 23.5±0.5 |
ERPUB14 | 14 | 23.5±0.2 | 24.5±0.5 |
ERPUB15 | 15 | 25.3±0.2 | 25.8±0.5 |
ERPUB16 | 16 | 25.3±0.2 | 25.8±0.5 |
ERPUB18 | 18 | 32.7±0.3 | 27.8±0.5 |
ERPUB20 | 20 | 32.7±0.3 | 27.8±0.5 |
ERPUB22 | 22 | 40±0.3 | 36.5±0.5 |
ERPUB25 | 25 | 40±0.3 | 36.5±0.5 |
ERPUB1/8 | 1/8 | 11±0.2 | 16.2±0.5 |
ERPUB3/16 | 3/16 | 13.5±0.2 | 18.7±0.5 |
ERPUB1/4 | 1/4 | 13.5±0.2 | 18.7±0.5 |
ERPUB5/16 | 5/16 | 15.2±0.2 | 19.2±0.5 |
ERPUB3/8 | 3/8 | 17.5±0.2 | 20.4±0.5 |
ERPUB1/2 | 1/2 | 21.5±0.2 | 23.5±0.5 |
