品名 (Type) | 规格 (Model) | 品名 (Type) | 规格 (Model) | 品名 (Type) | 规格 (Model) | 品名 (Type) | 规格 (Model) | ||||
管径 Tube (mm) | 内螺纹 Female (R) | 管径 Tube (inch) | 内螺纹 Female (R) | 管径 Tube (inch) | 内螺纹 Female (NPT) | 管径 Tube (mm) | 内螺纹 Female (NPT) | ||||
EPCF04-M5 | 04 | M5 | EPCF5/32-01 | 5/32 | 1/8 | EPCF5/32-N01 | 5/32 | 1/8 | EPCF04-N01 | 04 | 1/8 |
EPCF04-M6 | 04 | M6 | EPCF5/32-02 | 5/32 | 1/4 | EPCF5/32-N02 | 5/32 | 1/4 | EPCF04-N02 | 04 | 1/4 |
EPCF04-01 | 04 | 1/8 | EPCF3/16-01 | 3/16 | 1/8 | EPCF3/16-N01 | 3/16 | 1/8 | EPCF06-N01 | 06 | 1/8 |
EPCF04-02 | 04 | 1/4 | EPCF3/16-02 | 3/16 | 1/4 | EPCF3/16-N02 | 3/16 | 1/4 | EPCF06-N02 | 06 | 1/4 |
EPCF06-M5 | 06 | M5 | EPCF1/4-01 | 1/4 | 1/8 | EPCF1/4-N01 | 1/4 | 1/8 | EPCF06-N03 | 06 | 3/8 |
EPCF06-M6 | 06 | M6 | EPCF1/4-02 | 1/4 | 1/4 | EPCF1/4-N02 | 1/4 | 1/4 | EPCF06-N04 | 06 | 1/2 |
EPCF06-01 | 06 | 1/8 | EPCF1/4-03 | 1/4 | 3/8 | EPCF1/4-N03 | 1/4 | 3/8 | EPCF08-N01 | 08 | 1/8 |
EPCF06-02 | 06 | 1/4 | EPCF1/4-04 | 1/4 | 1/2 | EPCF1/4-N04 | 1/4 | 1/2 | EPCF08-N02 | 08 | 1/4 |
EPCF06-03 | 06 | 3/8 | EPCF5/16-01 | 5/16 | 1/8 | EPCF5/16-N01 | 5/16 | 1/8 | EPCF08-N03 | 08 | 3/8 |
EPCF06-04 | 06 | 1/2 | EPCF5/16-02 | 5/16 | 1/4 | EPCF5/16-N02 | 5/16 | 1/4 | EPCF08-N04 | 08 | 1/2 |
EPCF08-01 | 08 | 1/8 | EPCF5/16-03 | 5/16 | 3/8 | EPCF5/16-N03 | 5/16 | 3/8 | EPCF10-N01 | 10 | 1/8 |
EPCF08-02 | 08 | 1/4 | EPCF5/16-04 | 5/16 | 1/2 | EPCF5/16-N04 | 5/16 | 1/2 | EPCF10-N02 | 10 | 1/4 |
EPCF08-03 | 08 | 3/8 | EPCF3/8-01 | 3/8 | 1/8 | EPCF3/8-N01 | 3/8 | 1/8 | EPCF10-N03 | 10 | 3/8 |
EPCF08-04 | 08 | 1/2 | EPCF3/8-02 | 3/8 | 1/4 | EPCF3/8-N02 | 3/8 | 1/4 | EPCF10-N04 | 10 | 1/2 |
EPCF10-01 | 10 | 1/8 | EPCF3/8-03 | 3/8 | 3/8 | EPCF3/8-N03 | 3/8 | 3/8 | EPCF12-N01 | 12 | 1/8 |
EPCF10-02 | 10 | 1/4 | EPCF3/8-04 | 3/8 | 1/2 | EPCF3/8-N04 | 3/8 | 1/2 | EPCF12-N02 | 12 | 1/4 |
EPCF10-03 | 10 | 3/8 | EPCF1/2-01 | 1/2 | 1/8 | EPCF1/2-N01 | 1/2 | 1/8 | EPCF12-N03 | 12 | 3/8 |
EPCF10-04 | 10 | 1/2 | EPCF1/2-02 | 1/2 | 1/4 | EPCF1/2-N02 | 1/2 | 1/4 | EPCF12-N04 | 12 | 1/2 |
EPCF12-01 | 12 | 1/8 | EPCF1/2-03 | 1/2 | 3/8 | EPCF1/2-N03 | 1/2 | 3/8 | EPCF14-N01 | 14 | 1/8 |
EPCF12-02 | 12 | 1/4 | EPCF1/2-04 | 1/2 | 1/2 | EPCF1/2-N04 | 1/2 | 1/2 | EPCF14-N02 | 14 | 1/4 |
EPCF12-03 | 12 | 3/8 | EPCF14-N03 | 14 | 3/8 | ||||||
EPCF12-04 | 12 | 1/2 | EPCF14-N04 | 14 | 1/2 | ||||||
EPCF14-01 | 14 | 1/8 | EPCF16-N01 | 16 | 1/8 | ||||||
EPCF14-02 | 14 | 1/4 | EPCF16-N02 | 16 | 1/4 | ||||||
EPCF14-03 | 14 | 3/8 | EPCF16-N03 | 16 | 3/8 | ||||||
EPCF14-04 | 14 | 1/2 | EPCF16-N04 | 16 | 1/2 | ||||||
EPCF16-01 | 16 | 1/8 | |||||||||
EPCF16-02 | 16 | 1/4 | |||||||||
EPCF16-03 | 16 | 3/8 | |||||||||
EPCF16-04 | 16 | 1/2 |
