Previous : Bulkhead Union（PM）
Next : Union Connector（PU）
| Type | Model | Type | Model | Type | Model | Type | Model | ||||
| Tube(mm) | Thread(R) | Tube(mm) | Thread(NPT) | Tube(Inch) | Thread(R) | Tube(Inch) | Thread(NPT) | ||||
| PMF04-M5 | 04 | M5 | |||||||||
| PMF04-M6 | 04 | M6 | |||||||||
| PMF04-01 | 04 | 1/8 | PMF04-N01 | 04 | NPT1/8 | PMF5/32-01 | 5/32 | 1/8 | PMF5/32-N01 | 5/32 | NPT1/8 |
| PMF04-02 | 04 | 1/4 | PMF04-N02 | 04 | NPT1/4 | PMF5/32-02 | 5/32 | 1/4 | PMF5/32-N02 | 5/32 | NPT1/4 |
| PMF06-M5 | 06 | M5 | PMF3/16-01 | 3/16 | 1/8 | PMF3/16-N01 | 3/16 | NPT1/8 | |||
| PMF06-M6 | 06 | M6 | PMF3/16-02 | 3/16 | 1/4 | PMF3/16-N02 | 3/16 | NPT1/4 | |||
| PMF06-01 | 06 | 1/8 | PMF06-N01 | 06 | NPT1/8 | PMF1/4-01 | 1/4 | 1/8 | PMF1/4-N01 | 1/4 | NPT1/8 |
| PMF06-02 | 06 | 1/4 | PMF06-N02 | 06 | NPT1/4 | PMF1/4-02 | 1/4 | 1/4 | PMF1/4-N02 | 1/4 | NPT1/4 |
| PMF06-03 | 06 | 3/8 | PMF06-N03 | 06 | NPT3/8 | PMF1/4-03 | 1/4 | 3/8 | PMF1/4-N03 | 1/4 | NPT3/8 |
| PMF06-04 | 06 | 1/2 | PMF06-N04 | 06 | NPT1/2 | PMF1/4-04 | 1/4 | 1/2 | PMF1/4-N04 | 1/4 | NPT1/2 |
| PMF08-01 | 08 | 1/8 | PMF08-N01 | 08 | NPT1/8 | PMF5/16-01 | 5/16 | 1/8 | PMF5/16-N01 | 5/16 | NPT1/8 |
| PMF08-02 | 08 | 1/4 | PMF08-N02 | 08 | NPT1/4 | PMF5/16-02 | 5/16 | 1/4 | PMF5/16-N02 | 5/16 | NPT1/4 |
| PMF08-03 | 08 | 3/8 | PMF08-N03 | 08 | NPT3/8 | PMF5/16-03 | 5/16 | 3/8 | PMF5/16-N03 | 5/16 | NPT3/8 |
| PMF08-04 | 08 | 1/2 | PMF08-N04 | 08 | NPT1/2 | PMF5/16-04 | 5/16 | 1/2 | PMF5/16-N04 | 5/16 | NPT1/2 |
| PMF10-01 | 10 | 1/8 | PMF10-N01 | 10 | NPT1/8 | PMF3/8-01 | 3/8 | 1/8 | PMF3/8-N01 | 3/8 | NPT1/8 |
| PMF10-02 | 10 | 1/4 | PMF10-N02 | 10 | NPT1/4 | PMF3/8-02 | 3/8 | 1/4 | PMF3/8-N02 | 3/8 | NPT1/4 |
| PMF10-03 | 10 | 3/8 | PMF10-N03 | 10 | NPT3/8 | PMF3/8-03 | 3/8 | 3/8 | PMF3/8-N03 | 3/8 | NPT3/8 |
| PMF10-04 | 10 | 1/2 | PMF10-N04 | 10 | NPT1/2 | PMF3/8-04 | 3/8 | 1/2 | PMF3/8-N04 | 3/8 | NPT1/2 |
| PMF12-01 | 12 | 1/8 | PMF12-N01 | 12 | NPT1/8 | PMF1/2-01 | 1/2 | 1/8 | PMF1/2-N01 | 1/2 | NPT1/8 |
| PMF12-02 | 12 | 1/4 | PMF12-N02 | 12 | NPT1/4 | PMF1/2-02 | 1/2 | 1/4 | PMF1/2-N02 | 1/2 | NPT1/4 |
| PMF12-03 | 12 | 3/8 | PMF12-N03 | 12 | NPT3/8 | PMF1/2-03 | 1/2 | 3/8 | PMF1/2-N03 | 1/2 | NPT3/8 |
| PMF12-04 | 12 | 1/2 | PMF12-N04 | 12 | NPT1/2 | PMF1/2-04 | 1/2 | 1/2 | PMF1/2-N04 | 1/2 | NPT1/2 |
| PMF14-01 | 14 | 1/8 | PMF14-N01 | 14 | NPT1/8 | ||||||
| PMF14-02 | 14 | 1/4 | PMF14-N02 | 14 | NPT1/4 | ||||||
| PMF14-03 | 14 | 3/8 | PMF14-N03 | 14 | NPT3/8 | ||||||
| PMF14-04 | 14 | 1/2 | PMF14-N04 | 14 | NPT1/2 | ||||||
| PMF16-01 | 16 | 1/8 | PMF16-N01 | 16 | NPT1/8 | ||||||
| PMF16-02 | 16 | 1/4 | PMF16-N02 | 16 | NPT1/4 | ||||||
| PMF16-03 | 16 | 3/8 | PMF16-N03 | 16 | NPT3/8 | ||||||
| PMF16-04 | 16 | 1/2 | PMF16-N04 | 16 | NPT1/2 | ||||||
