规格尺寸 Specifications and dimensions
| 规格 Specifications | 管外径 Pipe OD(mm) | 规格 Specifications | 管外径 Pipe OD(inch) |
TRPUB04 | 4 | TRPUB3/16 | 3/16 |
TRPUB05 | 5 | TRPUB1/4 | 1/4 |
TRPUB06 | 6 | TRPUB5/16 | 5/16 |
TRPUB07 | 7 | TRPUB3/8 | 3/8 |
TRPUB08 | 8 | TRPUB1/2 | 1/2 |
TRPUB09 | 9 | ||
TRPUB10 | 10 | ||
TRPUB11 | 11 | ||
TRPUB12 | 12 | ||
TRPUB14 | 14 |
外形尺寸 Overall dimensions
规格 Specifications | D | A | L |
TRPUB04 | 4 | 11±0.2 | 17.5±0.5 |
TRPUB05 | 5 | 13±0.2 | 18.5±0.5 |
TRPUB06 | 6 | 13±0.2 | 18.5±0.5 |
TRPUB07 | 7 | 15±0.2 | 19±0.5 |
TRPUB08 | 8 | 15±0.2 | 19±0.5 |
TRPUB09 | 9 | 18.5±0.2 | 20.5±0.5 |
TRPUB10 | 10 | 18.5±0.2 | 20.5±0.5 |
TRPUB11 | 11 | 20.5±0.2 | 23.5±0.5 |
TRPUB12 | 12 | 20.5±0.2 | 23.5±0.5 |
TRPUB14 | 14 | 23±0.2 | 25±0.5 |
TRPUB3/16 | 3/16 | 13±0.2 | 18.5±0.5 |
TRPUB1/4 | 1/4 | 13±0.2 | 18.5±0.5 |
TRPUB5/16 | 5/16 | 15±0.2 | 19±0.5 |
TRPUB3/8 | 3/8 | 18.5±0.2 | 20.5±0.5 |
TRPUB1/2 | 1/2 | 20.5±0.2 | 23.5±0.5 |
