规格尺寸 Specifications and dimensions
规格 Specifications | 管外径 Pipe OD(mm) | 外径 Pipe OD(mm) | 孔径 Bore Size (mm) | 规格 Specifications | 管外径 Pipe OD(inch) | 管外径 Pipe OD(inch) | 孔径 Bore Size (mm) |
TRPU04 | 4 | 4 | 3.2 | TRPU3/16 | 3/16 | 3/16 | 4 |
TRPU05 | 5 | 5 | 4 | TRPU1/4 | 1/4 | 1/4 | 5 |
TRPU06 | 6 | 6 | 5 | TRPU5/16 | 5/16 | 5/16 | 7 |
TRPU07 | 7 | 7 | 6 | TRPU3/8 | 3/8 | 3/8 | 9 |
TRPU08 | 8 | 8 | 7 | TRPU1/2 | 1/2 | 1/2 | 11 |
TRPU09 | 9 | 9 | 8 | ||||
| TRPU10 | 10 | 10 | 9 | ||||
| TRPU11 | 11 | 11 | 10 | ||||
TRPU12 | 12 | 12 | 11 | ||||
TRPU14 | 14 | 14 | 13 |
外形尺寸 Overall dimensions
规 格 Specifications | DI | D2 | A1 | A2 | B | L |
TRPU04 | 4 | 4 | 11±0.2 | 11±0.2 | 3.2±0.12 | 33±0.5 |
TRPU05 | 5 | 5 | 13±0.2 | 13±0.2 | 4±0.12 | 36±0.5 |
TRPU06 | 6 | 6 | 13±0.2 | 13±0.2 | 5±0.12 | 36±0.5 |
| TRPU07 | 7 | 7 | 15±0.2 | 15±0.2 | 6±0.12 | 39.5±0.5 |
TRPU08 | 8 | 8 | 15±0.2 | 15±0.2 | 7±0.12 | 39.5±0.5 |
TRPU09 | 9 | 9 | 18.5±0.2 | 18.5±0.2 | 8±0.12 | 47.5±0.5 |
TRPU10 | 10 | 10 | 18.5±0.2 | 18.5±0.2 | 9±0.12 | 47.5±0.5 |
TRPU11 | 11 | 11 | 20.5±0.2 | 20.5±0.2 | 10±0.12 | 52±0.5 |
TRPU12 | 12 | 12 | 20.5±0.2 | 20.5±0.2 | 11±0.12 | 51±0.5 |
TRPU14 | 14 | 14 | 23±0.2 | 23±0.2 | 13±0.12 | 56±0.5 |
TRPU3/16 | 3/16 | 3/16 | 13±0.2 | 13±0.2 | 4±0.12 | 36±0.5 |
TRPU1/4 | 1/4 | 1/4 | 13±0.2 | 13±0.2 | 5±0.12 | 36±0.5 |
TRPU5/16 | 5/16 | 5/16 | 15±0.2 | 15±0.2 | 7±0.12 | 39.5±0.5 |
TRPU3/8 | 3/8 | 3/8 | 18.5±0.2 | 18.5±0.2 | 9±0.12 | 47.5±0.5 |
TRPU1/2 | 1/2 | 1/2 | 20.5±0.2 | 20.5±0.2 | 11±0.12 | 51±0.5 |
