规格尺寸 Specifications and dimensions
| 规 格 Specifications | 管外径 Pipe OD(mm) | 管外径 Pipe OD(mm) | 孔径 Bore Size (mm) |
ERPG5-3/2.1 | 3 | 5 | 2.1 |
ERPG5/3.5-3/2.1 | 3 | 5 | 3.5-2.1 |
ERPG6-4/3.5 | 4 | 6 | 3.5 |
ERPG7-5/3.5 | 5 | 7 | 3.5 |
ERPG7/4-5/3.5 | 5 | 7 | 4-3.5 |
ERPG8-6/5 | 6 | 8 | 5 |
ERPG10-7/5 | 7 | 10 | 5 |
ERPG10/5.5-8/5 | 8 | 10 | 5.5-5 |
ERPG12/8-8/5.5 | 8 | 12 | 8-5.5 |
ERPG12-10/8 | 10 | 12 | 8 |
ERPG12/10-10/8 | 10 | 12 | 10-8 |
ERPG14/10-10/8 | 10 | 14 | 10-8 |
ERPG14-12/10 | 12 | 14 | 10 |
ERPG14/11-12/10 | 12 | 14 | 11-10 |
ERPG16/12-12/10 | 12 | 16 | 12-10 |
| ERPG16/12-14/10 | 14 | 16 | 12-10 |
ERPG18/14-14/10 | 14 | 18 | 14-10 |
ERPG18/14-16/12 | 16 | 18 | 14-12 |
ERPG20/16-14/10 | 14 | 20 | 16-10 |
ERPG20-16/12 | 16 | 20 | 12 |
ERPG20/16-16/12 | 16 | 20 | 16-12 |
外形尺寸 Overall dimensions
规 格 Specifications | DI | D2 | A1 | A2 | B1 | B2 | L |
ERPG5-3/2.1 | 3 | 5 | 13.5±0.2 | 13.5±0.2 | 2.1±0.12 | 2.1±0.12 | 35.8±0.5 |
ERPG5/3.5-3/2.1 | 3 | 5 | 13.5±0.2 | 13.5±0.2 | 2.1±0.12 | 3.5±0.12 | 35.8±0.5 |
ERPG6-4/3.5 | 4 | 6 | 11±0.2 | 13.5±0.2 | 3.5±0.12 | 3.5±0.12 | 33±0.5 |
ERPG7-5/3.5 | 5 | 7 | 15.2±0.2 | 15.2±0.2 | 3.5±0.12 | 3.5±0.12 | 41.2±0.5 |
ERPG7/4-5/3.5 | 5 | 7 | 15.2±0.2 | 15.2±0.2 | 3.5±0.12 | 4.0±0.12 | 41.2±0.5 |
ERPG8-6/5 | 8 | 6 | 13.5±0.2 | 15.2±0.2 | 5.0±0.12 | 5.0±0.12 | 35±0.5 |
ERPG10-7/5 | 7 | 10 | 15.2±0.2 | 17.5±0.2 | 5.0±0.12 | 5.0±0.12 | 38±0.5 |
ERPG10/5.5-8/5 | 8 | 10 | 15.2±0.2 | 17.5±0.2 | 5.0±0.12 | 5.5±0.12 | 38±0.5 |
ERPG12/8-8/5.5 | 8 | 12 | 15.2±0.2 | 21.5±0.2 | 5.5±0.12 | 8.0±0.12 | 45±0.5 |
ERPG12-10/ | 10 | 12 | 17.5±0.2 | 21.5±0.2 | 8.0±0.12 | 8.0±0.12 | 44.4±0.5 |
ERPG12/10-10/8 | 10 | 12 | 17.5±0.2 | 21.5±0.2 | 8.0±0.12 | 10±0.12 | 44.4±0.5 |
ERPG14/10-10/8 | 10 | 14 | 17.5±0.2 | 23.5±0.2 | 8.0±0.12 | 10±0.12 | 48.5±0.5 |
ERPG14-12/10 | 12 | 14 | 21.5±0.2 | 23.5±0.2 | 10±0.12 | 10±0.12 | 48.5±0.5 |
ERPG14/11-12/10 | 12 | 14 | 21.5±0.2 | 23.5±0.2 | 10±0.12 | 11±0.12 | 48.5±0.5 |
ERPG16/12-12/10 | 12 | 16 | 23.5±0.2 | 25.3±0.2 | 10±0.12 | 12±0.12 | 50.5±0.5 |
ERPG16/12-14/10 | 14 | 16 | 23.5±0.2 | 25.3±0.2 | 10±0.12 | 12±0.12 | 50.5±0.5 |
ERPG18/14-14/10 | 14 | 18 | 25.3±0.2 | 32.7±0.2 | 10±0.12 | 14±0.12 | 55.8±0.5 |
| ERPG18/14-16/12 | 16 | 18 | 25.3±0.2 | 32.7±0.2 | 12±0.12 | 14±0.12 | 55.8±0.5 |
ERPG20/16-14/10 | 14 | 20 | 25.3±0.2 | 32.7±0.2 | 10±0.12 | 16±0.12 | 55.8±0.5 |
ERPG20-16/12 | 16 | 20 | 25.3±0.2 | 32.7±0.2 | 12±0.12 | 12±0.12 | 55.8±0.5 |
ERPG20/16-16/12 | 16 | 20 | 25.3±0.2 | 32.7±0.2 | 12±0.12 | 16±0.12 | 55.8±0.5 |
