End Cap

Previous : Straight Connector

Next : Reducer

content

Specifications and dimensions

Specifications

Pipe OD(mm)

Specifications

Pipe OD(inch)

TRPUB04

4

TRPUB3/16

3/16

TRPUB05

5

TRPUB1/4

1/4

TRPUB06

6

TRPUB5/16

5/16

TRPUB07

7

TRPUB3/8

3/8

TRPUB08

8

TRPUB1/2

1/2

TRPUB09

9



TRPUB10

10



TRPUB11

11



TRPUB12

12



TRPUB14

14


Overall dimensions

Specifications

D

A

L

TRPUB04

4

11±0.2

17.5±0.5

TRPUB05

5

13±0.2

18.5±0.5

TRPUB06

6

13±0.2

18.5±0.5

TRPUB07

7

15±0.2

19±0.5

TRPUB08

8

15±0.2

19±0.5

TRPUB09

9

18.5±0.2

20.5±0.5

TRPUB10

10

18.5±0.2

20.5±0.5

TRPUB11

11

20.5±0.2

23.5±0.5

TRPUB12

12

20.5±0.2

23.5±0.5

TRPUB14

14

23±0.2

25±0.5

TRPUB3/16

3/16

13±0.2

18.5±0.5

TRPUB1/4

1/4

13±0.2

18.5±0.5

TRPUB5/16

5/16

15±0.2

19±0.5

TRPUB3/8

3/8

18.5±0.2

20.5±0.5

TRPUB1/2

1/2

20.5±0.2

23.5±0.5
