Reducer

Previous : End Cap

Next : Gas Block Connector

content

Specifications and dimensions

Specifications

Pipe OD(mm)

Pipe OD(mm)

Bore Size (mm)

ERPG5-3/2.1

3

5

2.1

ERPG5/3.5-3/2.1

3

5

3.5-2.1

ERPG6-4/3.5

4

6

3.5

ERPG7-5/3.5

5

7

3.5

ERPG7/4-5/3.5

5

7

4-3.5

ERPG8-6/5

6

8

5

ERPG10-7/5

7

10

5

ERPG10/5.5-8/5

8

10

5.5-5

ERPG12/8-8/5.5

8

12

8-5.5

ERPG12-10/8

10

12

8

ERPG12/10-10/8

10

12

10-8

ERPG14/10-10/8

10

14

10-8

ERPG14-12/10

12

14

10

ERPG14/11-12/10

12

14

11-10

ERPG16/12-12/10

12

16

12-10

ERPG16/12-14/10

14

16

12-10

ERPG18/14-14/10

14

18

14-10

ERPG18/14-16/12

16

18

14-12

ERPG20/16-14/10

14

20

16-10

ERPG20-16/12

16

20

12

ERPG20/16-16/12

16

20

16-12


Overall dimensions

Specifications

DI

D2

A1

A2

B1

B2L

ERPG5-3/2.1

3

5

13.5±0.2

13.5±0.2

2.1±0.12

2.1±0.12

35.8±0.5

ERPG5/3.5-3/2.1

3

5

13.5±0.2

13.5±0.2

2.1±0.12

3.5±0.12

35.8±0.5

ERPG6-4/3.5

4

6

11±0.2

13.5±0.2

3.5±0.12

3.5±0.12

33±0.5

ERPG7-5/3.5

5

7

15.2±0.2

15.2±0.2

3.5±0.12

3.5±0.12

41.2±0.5

ERPG7/4-5/3.5

5

7

15.2±0.2

15.2±0.2

3.5±0.12

4.0±0.12

41.2±0.5

ERPG8-6/5

8

6

13.5±0.2

15.2±0.2

5.0±0.12

5.0±0.12

35±0.5

ERPG10-7/5

7

10

15.2±0.2

17.5±0.2

5.0±0.12

5.0±0.12

38±0.5

ERPG10/5.5-8/5

8

10

15.2±0.2

17.5±0.2

5.0±0.12

5.5±0.12

38±0.5

ERPG12/8-8/5.5

8

12

15.2±0.2

21.5±0.2

5.5±0.12

8.0±0.12

45±0.5

ERPG12-10/

10

12

17.5±0.2

21.5±0.2

8.0±0.12

8.0±0.12

44.4±0.5

ERPG12/10-10/8

10

12

17.5±0.2

21.5±0.2

8.0±0.12

10±0.12

44.4±0.5

ERPG14/10-10/8

10

14

17.5±0.2

23.5±0.2

8.0±0.12

10±0.12

48.5±0.5

ERPG14-12/10

12

14

21.5±0.2

23.5±0.2

10±0.12

10±0.12

48.5±0.5

ERPG14/11-12/10

12

14

21.5±0.2

23.5±0.2

10±0.12

11±0.12

48.5±0.5

ERPG16/12-12/10

12

16

23.5±0.2

25.3±0.2

10±0.12

12±0.12

50.5±0.5

ERPG16/12-14/10

14

16

23.5±0.2

25.3±0.2

10±0.12

12±0.12

50.5±0.5

ERPG18/14-14/10

14

18

25.3±0.2

32.7±0.2

10±0.12

14±0.12

55.8±0.5

ERPG18/14-16/12

16

18

25.3±0.2

32.7±0.2

12±0.12

14±0.12

55.8±0.5

ERPG20/16-14/10

14

20

25.3±0.2

32.7±0.2

10±0.12

16±0.12

55.8±0.5

ERPG20-16/12

16

20

25.3±0.2

32.7±0.2

12±0.12

12±0.12

55.8±0.5

ERPG20/16-16/12

16

20

25.3±0.2

32.7±0.2

12±0.12

16±0.12

55.8±0.5
